| TSP Lab | DelThem - Delete unnecessary files | DelThem |
|---|
| Menu | Menuitem | Shortcut(s) | Meaning |
|---|---|---|---|
| [Log] | |||
| Find line containing... | (Ctrl-F) | Find text in log window | |
| Find next matching line | (F3) | Find next occurrence of text in log window | |
| Details | Detail level of logging (Off, Normal, Detailed or Debug) | ||
| [Options] | |||
| Go on / Pause | (CTRL-P) | Runs / Halts processing | |
| Test CDR folder deletion | ( )
| Check how much disk space the current configuration would free. Also shows deletable sum of _N folders. | |
| Auto scroll | (ScrollLock, or   )
| Allow automatic scrolling of the log screen | |
| Save settings now! | Save actual settings into the configuration (DelThem.ini) file |
| Section | Entry | Example | Meaning |
|---|---|---|---|
| [Position] | |||
| iLeft | 284 | Position of the program module on the display screen | |
| iTop | 69 | Position of the program module on the display screen | |
| iWidth | 768 | Position of the program module on the display screen | |
| iHeight | 558 | Position of the program module on the display screen | |
| [Delete] | |||
| szDeleteFileMask | d:\Sga\DelThem\Garbage\*.qqq | Mask of file specification to be deleted | |
| szDeleteFileMask... | d:\Sga\DelThem\Garbage\Garbage1\*.tmp | Additional file deleting specifications can be given by creating new definition entries. '...' should be replaced with any different text for the different entries. | |
| dwDeleteDelaySec | 100 | The minimal age (in sec) of files to be deleted | |
| dwDeleteCheckPeriodSec | 10 | The period time (in sec) of file checking operation | |
| [Options] | |||
| bGoonProcessing | True | True if processing is active | |
| bAutoScroll | True | (Refer to the [Options]/Auto-query monitors menu item!) | |
| [Delete CDRs] | |||
| dwCheckPeriodSec | 3 | Directory checking period. Loaded and logged at start-up. | |
| dwDiskSpaceLowLimitMB | 100000 | Deletion starts if the free space of the disk is lower than this value. | |
| sCdrFilesPath | c:\CDRfiles | Defines the path containing CDR folders and files to be deleted in case of low disk space | |
| sCdrDirPostfix | GyMon | Defines the postfix of the name of the folders to be deleted In case of absence of this entry, the program would apply the default value ("SgaMon") as the directory name postfix. In case of automatic deletion of GTP-CDR directories this entry must be defined and must have empty value ("sCdrDirPostfix="). | |
| sCdrFilesPath_0 | d:\SGAFiles | When a CDR subfolder is deleted then correspondig subfolder from this folder is also deleted. (At most 10 different folders can be defined.) | |
| sCdrDirPostfix_N | DiamS6 | Defines the postfix of the N'th subfolders to be deleted (N=1..9; defaults to the value of INI/[Delete CDRs]/sCdrDirPostfix) | |
| [Options] | |||
| bGoonProcessing | True | True if processing is active | |
| bAutoScroll | True | (Refer to the [Options]/Auto-query monitors menu item!) | |
| [Advanced] | |||
| sCaption | CDR folders | Alternative caption text for easy distinguishing amongst multiple instances of this module | |
| wLogDetailLevel | 3 | (Equals to the listed order; refer to the [Log]/Details menu item!) | |
| dwMaxLinesInLogWindow | 1000 | Number of lines in the log window on screen | |
| sLogFilesPath | d:\Sga\DelThem\LogFiles | Path for the Log files |
