| TSP Lab | DiamCx_CDR-Assembler - The Diameter Assembler for Cx | DiamCx_CDR-Assembler |
|---|
| Menu | Menuitem | Shortcut(s) | Meaning |
|---|---|---|---|
| [Log] | |||
| Find line containing... | (Ctrl-F) | Finds text in log window | |
| Find next matching line | (F3) | Finds next occurrence of text in log window | |
| Details | Detail level of logging (Off, Normal, Detailed, or Debug) | ||
| Backup "(IMSI--->MSISDN) Memory" entries | Entries of "(TMSI--->IMSI) Memory" are written into the corresponding binary backup files | ||
| [Actions] | |||
| Go on / Pause | (Ctrl-P, or   )
| Enables input data processing | |
| Flush CDR and other counters into log | Writes status counters into the log. These counters are being flushed in every 15 minutes. | ||
| Flush & reset CDR and other counters | Clears status counters after writing them into the log | ||
| [Options] | |||
| Auto scroll | (  )
| Allows automatic scrolling of the log screen | |
| Save settings | Saves actual settings into the configuration file |
| Section | Entry | Example | Meaning |
|---|---|---|---|
| [Position] | |||
| iLeft | 140 | Position of the program module on the display screen | |
| iTop | 72 | Position of the program module on the display screen | |
| iWidth | 995 | Position of the program module on the display screen | |
| iHeight | 694 | Position of the program module on the display screen | |
| [Options] | |||
| bAutoScroll | True | (Refer to the [Options]/Auto scroll menu item!) | |
| [IMSISDN Memory] | |||
| dwEntryLifeSec | 2592000 | Life time for each IMSI-MSISDN pair entry; given in seconds | |
| sBackupFile | c:\SgaIMSISDNbdb_BackupFile.bin | Path and file for saving IMSI-MSISDN pair entries | |
| bBackupPeriodic | True | If True then the IMSI-MSISDN memory is periodically saved into the backup file | |
| [Advanced] | |||
| wLogDetailLevel | 3 | (Equals to the listed order; refer to the [Log]/Details menu item!) | |
| dwMaxLinesInLogWindow | 1000 | Number of lines in the log window on screen | |
| wMaxCPUUsagePercent | 100 | Limit of CPU-usage for this module | |
| dwTransactionMaxElemCount | 10000 | Number of possibly active transactions at the same time | |
| dwTransactionMaxDurationSec | 15 | Time out value for Diameter transactions | |
| wOutFilePeriod | 15 | Period of creating CDR files (given in minutes) | |
| iOutFileCompressionLevel | 6 | Compression level for CDRs. 0 means compression is switched off | |
| dwOutFileUseCrypto | 1 | Enables encryption of CDR files; 0 means off | |
| sOutFilePathPrimary | e:\Diam-CDR\ | Path for CDRs | |
| sOutFilePathAlternate | f:\Diam-CDR-2 | Alternative path for CDRs when sOutFilePathPrimary is inaccessible | |
| dwOutFilePreallocationSize | 250000000 | Preallocation size of CDR files, in bytes | |
| dwOutFilePreallocationSize_IMSIindex | 25000000 | Preallocation size of IMSI index files, in bytes | |
| dwOutFilePreallocationSize_MSISDNindex | 25000000 | Preallocation size of MSISDN index files, in bytes | |
| sLogFilesPath | d:\Logfiles | Path for the LOG files | |
| sAlarmFilesPath | d:\Logfiles | Path for the output alarm files (info from the rejected users during IMS registration) |
