| Menu
| Menuitem
| Shortcut(s)
| Meaning
|
| [Log]
|
|
|
|
|
| Find line containing...
| (Ctrl-F)
| Finds text in log window
|
|
| Find next matching line
| (F3)
| Finds next occurrence of text in log window
|
|
| Details
|
| Detail level of logging (Off, Normal, Detailed, or Debug)
|
| [Actions]
|
|
|
|
|
| Allow client connection
| (Ctrl-A, or   )
| Allow Statistics Query clients to connect and query
|
|
| Re-enter client password
|
| The password used during the authentication can be re-entered
|
|
| Flush counters
|
| Writes status line counters into the log
|
|
| Flush and zero counter
|
| Writes the counters into the log and zeroes them
|
| [Options]
|
|
|
|
|
| Auto scroll
| (ScrollLock, or   )
| Allow automatic scrolling of the log screen
|
|
| Save settings
|
| Save actual settings into the configuration (Sga7N_GyDB_QueryServer_Stat.ini) file
|
| Section
| Entry
| Example
| Meaning
|
| [Position]
|
|
|
|
|
| iLeft
| 140
| Position of the program module on the display screen
|
|
| iTop
| 72
| Position of the program module on the display screen
|
|
| iWidth
| 995
| Position of the program module on the display screen
|
|
| iHeight
| 694
| Position of the program module on the display screen
|
| [Options]
|
|
|
|
|
| bAutoScroll
| True
| (Refer to the [Options]/Auto scroll menuitem!)
|
| [Validity Interval]
|
|
| A validity interval can be set. The server will send only records that are in this interval.
|
|
| StartTimeYear
| 2006
| Year of the StartTime of the validity interval
|
|
| StartTimeMonth
| 1
| Month of the StartTime
|
|
| StartTimeDay
| 1
| Day of the StartTime
|
|
| StartTimeHour
| 0
| Hour of the StartTime
|
|
| StartTimeMinute
| 0
| Minute of the StartTime
|
|
| StartTimeSecond
| 0
| Second of the StartTime
|
|
| bStartTimeDate
| 1
| If it is 1 the StartTime set above is applied.
|
|
| EndTimeYear
| 2010
| Year of the EndTime of the validity interval
|
|
| EndTimeMonth
| 12
| Month of the EndTime
|
|
| EndTimeDay
| 13
| Day of the EndTime
|
|
| EndTimeHour
| 23
| Hour of the EndTime
|
|
| EndTimeMinute
| 59
| Minute of the EndTime
|
|
| EndTimeSecond
| 59
| Second of the EndTime
|
|
| bEndTimeDate
| 1
| If it is 1 the EndTime set above is applied. When it is 0 EndTime will be the actual local time.
|
| [Advanced]
|
|
|
|
|
| wLogDetailLevel
| 3
| (Equals to the listed order; refer to the [LOG]/Details menuitem!)
|
| dwMaxLinesInLogWindow
| 1000
| Number of lines in the log window on screen
|
|
| sDataPath
| d:\StatCDR
| Path for statistical data files
|
|
| wDataFilePeriod
| 60
| Period of statistical database files.
It should be the same value as Sga7N_GyDB_Loader_Stat.ini/[Advanced]/wOutFilePeriod.
|
|
| sLogFilesPath
| d:\LogFiles
| Path for the LOG files
|
|
| sClientPassword
| password
| Password used during the authentication.
If it is not set a pop-up window will appear to enter it when the module has been started
| |
