| Menu
| Menuitem
| Shortcut(s)
| Meaning
|
| [Log]
|
|
|
|
|
| Find line containing...
| (Ctrl-F)
| Finds text in log window
|
|
| Find next matching line
| (F3)
| Finds next occurrence of text in log window
|
|
| Details
|
| Detail level of logging (Off, Normal, Detailed, or Debug)
|
| [Actions]
|
|
|
|
|
| Allow client connection
| (Ctrl-A, or   )
| Allow CDR Query clients to connect and query
|
|
| Flush counters
|
| Writes status line counters into the log
|
|
| Flush & reset counters
|
| Writes the counters into the log and zeroes them
|
| [Options]
|
|
|
|
|
| Auto scroll
| (  )
| Allow automatic scrolling of the log screen
|
|
| Save settings
|
| Save actual settings into the configuration (SgaBSSAPCDR_QueryServer.ini) file
|
| Section
| Entry
| Example
| Meaning
|
| [Position]
|
|
|
|
|
| iLeft
| 140
| Position of the program module on the display screen
|
|
| iTop
| 72
| Position of the program module on the display screen
|
|
| iWidth
| 995
| Position of the program module on the display screen
|
|
| iHeight
| 694
| Position of the program module on the display screen
|
| [Options]
|
|
|
|
|
| bAutoScroll
| True
| (Refer to the [Options]/Auto scroll menuitem!)
|
| [Sga-7N Authorizer]
|
|
|
|
|
| sRemoteIPaddress
| 40.30.20.10
| IP address of the SgaAutho module
|
|
| sQSuserName
| $QS-BSSAP$
| Used as the QS identifier while retrieving Oracle ("client") password from the SgaAutho module
|
| [Advanced]
|
|
|
|
|
| wLogDetailLevel
| 3
| (Equals to the listed order; refer to the [LOG]/Details menuitem!)
|
| dwMaxLinesInLogWindow
| 1000
| Number of lines in the log window on screen
|
|
| sDataPath
| d:\BSSAPCDR
| Path for BSSAP CDR files
|
|
| wDataFilePeriod
| 15
| Period of BSSAP CDR files.
It should be the same value as SgaBSSAPCDR.ini/[Advanced]/wOutFilePeriod.
|
|
| sLogFilesPath
| d:\LogFiles
| Path for the LOG files
|
|
| sDataFileIndices
| IMSI,MSISDN
| List of indices where the Query Server would look for existing entry.
|
|
| sLocalIPAddress
| 10.20.30.78
| Optional local IP address setting
|
|
| wLocalTCPport
| 7014
| TCP port for the incoming connections
|
|
| sCaption
| MSS1
| Alternative caption text for easy distinguishing amongst multiple instances of this module
|
|
| dwQueryIntervalSec
| 31536000
| CDR's are available for this time interval back from the current time
|
| [Log result details For these stations]
|
|
|
|
|
| 10.20.30.222
| Someone's machine
| Results are being logged in details for this station
| |
