| Menu
| Menuitem
| Shortcut(s)
| Meaning
|
| [Log]
|
|
|
|
|
| Find line containing...
| (Ctrl-F)
| Finds text in log window
|
|
| Find next matching line
| (F3)
| Finds next occurrence of text in log window
|
|
| Details
|
| Detail level of logging (Off, Normal, Detailed, or Debug)
|
|
| Omit per-LU (black & gray) lines from log window
|
| Use this menu to avoid overloading the CPU showing all details of transactions on the screen when
log level is 'Detailed' or 'Debug'. Details will be written into logfile.
|
| [Actions]
|
|
|
|
|
| Go on / Pause
| (Ctrl-P, or   )
| Allow periodic scanning of the working directory for Sga-7008.xxx files
|
| [Options]
|
|
|
|
|
| Auto scroll
| (ScrollLock, or   )
| Allow automatic scrolling of the log screen
|
|
| Save settings
|
| Save actual settings into the configuration (SgaDbLU.INI) file
|
| Section
| Entry
| Example
| Meaning
|
| [Position]
|
|
|
|
|
| iLeft
| 140
| Position of the program module on the display screen
|
|
| iTop
| 72
| Position of the program module on the display screen
|
|
| iWidth
| 995
| Position of the program module on the display screen
|
|
| iHeight
| 694
| Position of the program module on the display screen
|
| [Options]
|
|
|
|
|
| bAutoScroll
| True
| (Refer to the [OPTIONS]/Auto scroll menuitem!)
|
| [Remote Control]
|
|
|
|
|
| wLocalPort
| 9708
| Port number where the module listens to the remote control utility's connection
|
| [Advanced]
|
|
|
|
|
| wLogDetailLevel
| 3
| (Equals to the listed order; refer to the [LOG]/Details menuitem!)
|
| wMaxCPUUsagePercent
| 25
| Limit of CPU-usage for this module
|
|
| wRefreshInterval
| 1000
| Periodicity of input scanning, given in milliseconds
|
|
| dwMaxRecordCount
| 25000
| The actual LU statfile will contain at most this amount of records.
|
|
| dwMaxLinesInLogWindow
| 1000
| Number of lines in the log window on screen
|
|
| wFlushPeriod
| 900
| Period of creating statistics (LU) files
|
|
| sLogFilesPath
| d:\LogFiles
| Path for the LOG files
|
|
| sLUSPath
| d:\StatFiles
| Directory for LU statistics files
| |
