| Menu
| Menuitem
| Shortcut(s)/Button
| Meaning
|
| [Log]
|
|
|
|
|
| Find line containing...
| (Ctrl+F)
| Finds text in log window
|
|
| Find next matching line
| (F3)
| Finds next occurrence of text in log window
|
|
| Details
|
| Detail level of logging (Off, Normal, Detailed, or Debug)
|
| [Actions]
|
|
|
|
|
| Compress yesterday's SGA files now!
| (Ctrl+Y)
| Start compression of SGA files created yesterday
|
|
| Flush status-line counters into log now!
|
| Write status line counters into log file
|
|
| Flush & reset status-line counters now!
|
| Write status line counters into log file, and then reset to zero
|
| [Options]
|
|
|
|
|
| Auto scroll
| (  )
| Scrolls automatically the log window
|
|
| Save settings
|
| Save actual settings to configuration file
|
| Section
| Entry
| Example
| Meaning
|
| [Position]
|
|
|
|
|
| iLeft
| 9
| Position of the program module on the display screen
|
|
| iTop
| 9
| Position of the program module on the display screen
|
|
| iWidth
| 1010
| Position of the program module on the display screen
|
|
| iHeight
| 750
| Position of the program module on the display screen
|
| [Options]
|
|
|
|
|
| bAutoScroll
| True
| (Refer to the [Options]/Auto scroll menu item!)
|
| [SGA files]
|
|
|
|
|
| sFolderRoot
| E:\DataFiles-St1\
| Root folder for SGA files in daily subfolders to be compressed
|
|
| sFolderAndFilePrefix
| SgaMon
| Prefix of storage folders and files
|
|
| wFilePeriodMinutes
| 15
| Used for indexing, i.e., to create proper "*.SGAi" files
|
|
| iCompressionLevel
| 9
| Sets the compression level; 0..9
|
|
| dwUseCrypto
| 1
| Enables encryption; 0="don't encrypt"
|
|
| byTotalMax_OwnThreads
| 0
| Set a positive value to apply this limit, set 99 _not_ to apply this limit, set 0 (or leave empty) to limit by #CPUs; loaded on-the-fly
|
|
| byTotalMaxToStartMultiple_CPUusage
| 50
| Percent (%), loaded on-the-fly
|
|
| byTotalMaxToStartMultiple_DiskUsage
| 75
| Percent (%), loaded on-the-fly
|
|
| sLogicalDiskPerformanceInstanceName
| E:
| Sets the logical disk to be monitored
!--=======================================-->
|
| [Advanced]
|
|
|
|
|
| wLogDetailLevel
| 2
| Detail level of logging (Off, Normal, Detailed, or Debug)
|
|
| dwMaxLinesInLogWindow
| 1000
| Maximum number of lines in log window.
|
|
| sCaption
| Storage-1
| Alternative caption text for easy distinguishing amongst multiple instances of this module
|
|
| dwProcessAffinityMask
| 0xFFFFF
| Sets the process affinity
|
|
| sLogFilesPath
| d:\LogFiles
| Path to the log files.
|
