AITIA International, Inc.	SgaFileTraceServer - File Trace Server	SgaFileTraceServer

Query Server for Call Trace clients
`("SgaFileTraceServer")`

Features

Serves Call Trace client requets arriving from Monitor Poller through Super Monitor module
Reads "SGA" file storages, created by Message Store
Handles Storage#2 containing assembled messages generated by lower layer reassembler modules (e.g.: UDP Protocol Filter, TCP Reassembler module)
Uses authentication to ensure that only clients with proper right can start a query
Requires SgaFileTraceFilter.dll providing Call Trace option evaluation
Cooperates with SgaFileQueryPwd.dll for authentication information
Uses zlib1.dll to decompress SGA files
Logs connections, queries and file operations

Menu	Menuitem	Shortcut(s)/Button	Meaning
[Log]
	Find line containing...	(Ctrl+F)	Finds text in log window
	Find next matching line	(F3)	Finds next occurrence of text in log window
	Details		Detail level of logging (Off, Normal, Detailed, or Debug)
[Actions]
	Allow client connection	(Ctrl+A / )	Enable/Disable client connections
	Flush counters		Write status line counters into log file
	Flush & reset counters		Write status line counters into log file, and then reset to zero
[Options]
	Auto scroll	( )	Scrolls automatically the log window
	Save settings		Save actual settings to configuration file

Availability Shows availability information about Storage#2; checked in each 10 seconds
- available time interval in days
- start and end date and time (in UTC)
Uptime: Time elapsed since module has been started up;
- hovering over: Start date and time
- left-click: Kernel and user time
- right-click: Put a line into the log with the used DLL and its version
Clients: Number of currently connected clients
Traces: Number of traces currently running
N trace (re)requests processed: Number of processed trace requests and rerequest
N skipped: Number of skipped trace requests
N SGA items checked: Number of checked message items
N found: Number of found message items as result for requests

Section	Entry	Example	Meaning
[Position]
	iLeft	9	Position of the program module on the display screen
	iTop	9	Position of the program module on the display screen
	iWidth	1010	Position of the program module on the display screen
	iHeight	750	Position of the program module on the display screen
[Options]
	bAutoScroll	True	(Refer to the [Options]/Auto scroll menu item!)
[Advanced]
	wLogDetailLevel	2	Detail level of logging (Off, Normal, Detailed, or Debug)
	dwMaxLinesInLogWindow	1000	Maximum number of lines in log window.
	wSgaFilePeriodMin	15	Resolution of the stored "SGA" files (in minute)
	sSgaFilesPath	d:\Storage#2	Path for the assembled messages from transport layer reassembler modules. Note: In Storage#2 first letter of link ID is made uppercase by Message Store module receiving messages from reassembler modules.
	sSgaDirAndFilePrefix	SgaMon	Prefix of storage files
	sLogFilesPath	d:/LogFiles	Path to the log files.
	sLocalIPAddress	116.117.118.119	Optional local IP address binding

v1.10

v0.92

v0.91

v1.00

(n) Added IMSI,IMEI,MSISDN search capability (normal and joker) for compressed, and uncompressed PFCP messages

v0.99

v0.98

v0.97

v0.91

(f) SIP search: Cseq/num and Cap4/serviceKey were found even if not fully matched.

v0.90
